Valstat® VS 20 Active AC Static Eliminator

Valstat® VS 20 Active AC Static Eliminator

(Shock-less static discharge bars)

Valstat® VS 20 AC static charge eliminators are low-priced shock-less static discharge bars, designed for neutralising electrostatic charges from moving surfaces. Electrodes, provided along the active length of the bar, generate ions of both polarities, ensuring that positive and negative charges are removed from the charged target. Valstat® PS 70 S power sources are designed to provide high voltage AC supply to Valstat® VS 20 static eliminating bars. They give stable high voltage output even under severe conditions.
Manufactured by: Valence Electrons Private Limited, India

  • FEATURES
  • BENEFITS
  • RESOURCES
  • GET A QUOTE
More
      Technical Details
  • Shock-less; no damage when electrodes are earthed
  • Powder coated aluminum and engineered plastic construction
  • Discharge range of 10-40 mm
  • Standard design suitable for speeds up to 350 m/min. For higher speeds, other options available
  • Regular sizes for web widths up to 4.5 m. Custom-made higher lengths possible
  • Standard 2 m HV interconnecting cable
  •   Valstat PS 70 S HV power source
  • 230 V, 50/60 Hz, single phase input
  • Stable HV output, with in-built current limit
  • Three HV output connectors for VS 20 bars
  • 2 m input cable with built-in fuse and power switch
  • Shock-less and spark-less
  • Sturdy, reliable, construction
  • Maintenance free, except for occasional cleaning
  • Easy installation, commissioning
  • Compact, rugged, dust-proof, powder coated construction, fabricated of mild steel
  • Very low power consumption - 50 W
  • Provides stable high voltage output even under severe operating conditions
  • Easy installation, commissioning
